Piston Air Compressor, Size 1/4", 1615 RPM MPN:3HBB-19-M323A
Piston Air Compressor, Size 1/4", 1615 RPM
The Gast 3HBB-19-M323A is an oil-free, twin-cylinder piston air compressor with a reciprocating design. It runs on 24V DC power at a rated 0.42 hp output, in a tankless configuration. The oil-free design means the compression chamber runs without lubricant. It provides a free-air flow rate of 2.4 cfm, and a maximum continuous pressure of 100 psi. It has a maximum speed of 1,615 RPM, a full-load current of 19.5 A, and a measured sound level of 75 dBA. The operating temperature range is 41 to 104°F. Construction includes an aluminum cylinder, a brushed DC motor, and stainless steel valves. Enclosure type is clean dust free. Air connections are 1/4 in NPT inlet and outlet. Overall dimensions are 12.16 x 10.93 x 5.82 in (L x W x H). Duty cycle: continuous. Rated life expectancy: 2,000 hr.
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 27 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 17.00
- Package Width: 15.00
- Package Height: 12.00
- Package Weight: 15.00
Product info last updated on March 15, 2026 2:42pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
