RIB® Dry Contact Input Relay RIBM01ZNDC Panel 4" x 2.875" 120VAC 30A DPDT
The RIBM01ZNDC is a versatile dry contact input relay from Functional Devices, ideal for a wide range of applications. This self-powered relay can be activated by various dry-contacts, including thermostats, switches, and other relays, making it a convenient solution for various installations. Its isolated relay contacts can be wired to switch any power-load or low-voltage load, offering flexibility and reliability. Suitable for use in various industries, including commercial and industrial settings, this relay provides a simple and efficient way to control and manage power loads, making it a valuable addition to any system.
Top product features:
- The dry contact input can be activated by a wide range of dry-contacts such as thermostats, switches, other relays, or solid-state switches.
- The relay provides the low-voltage (class power needed to activate the relay, allowing it to be self-powered.
- The relay contacts are isolated from the input power and the dry contact input, allowing them to be wired to switch any other power-load or low-voltage load.
Top product applications:
- Temperature control systems
- Security systems
- Control systems for industrial machinery
Rib® dry contact input relay ribm01zndc panel 4" x 2.875" 120vac 30a dpdt the dry contact input rib series offers all the advantages of the standard rib line; plus it can be activated by a wide range of dry-contacts such as thermostats switches other relays solid-state switches etc. The dry contact input rib provides the low-voltage (class 2) power needed to activate the relay (self-powered) - just close the dry-contact input. The power to energize the relay can be brought to the relay on a separate pair of wires along with the control output of the controller or can be a local power source near the relay. The relay contacts are isolated from the input power and the dry contact input; thus they can be wired to switch any other power-load or low-voltage load (see specifications for contact ratings). One model can be used for many installations (model rib21cdc can operate from any voltage from 120vac - 277vac; see specifications for the input power of other models).
Additional Information
- UNSPSC: 39122300
- Brand: Functional Devices
- Package Quantity: 1
- Country of Origin: US
- FOB Origin: JA
- Ships by: PARCEL
- Comes in a kit: No
- Newly added to catalog: No
- Item is on Clearance: No
- Contains Hazardous Materials: No
- CA Proposition 65 Applies: No
- Package Length: 2.88
- Package Width: 4.00
- Package Height: 1.75
- Package Weight: 0.35
