Energy Logger, 3-Phase Power Quality Analyzer, 4 Voltage/3 Current Channels, 1000V MPN:FLUKE 1734/B

• FLUKE 1734/B is an energy logger and power quality analyzer for measuring and recording electrical parameters on single-phase, split-phase, and three-phase systems. It supports data logging and monitors voltage, current, power, and power factor, with harmonic capture up to the 50th harmonic. The unit uses a color LCD touch screen with 480 x 272 resolution and includes wired and wireless communication options for transferring and reviewing data.

  Key Features of the FLUKE 1734/B Energy Logger:


  • Phase Compatibility: Works on single, split, and three-phase systems.
  • Voltage and Current Channels: 4 voltage channels and 3 current channels support multi-parameter measurement.
  • Measurement Range: Measures up to 1000V AC/DC, 6000A AC, and 1000A DC.
  • Accuracy: Voltage accuracy is ±0.2% and current accuracy is ±1%.
  • Data Logging and Storage: Built-in data logging with 2 GB storage for recorded measurements.
  • Display: Color LCD touch screen with 480 x 272 resolution for viewing readings and setup information.
  • Sampling and Response: 10.24 kHz sampling rate, 5 kHz AC response, and 200 ns minimum transient duration.
  • Power Analysis: Measures power factor from -1 to 1 and captures harmonics through the 50th order.
  • Connectivity: Bluetooth, Wi-Fi, USB-A, and USB-Mini communication options.
  • Included Accessories: Supplied with alligator clips, magnetic voltage probes, color coding set, Energy Analyze Plus software, line cords, magnetic hanging strap, power supply, soft case, voltage test leads, and WiFi/BLE adapter.
  • Ratings: IP50
  • CAT III 1000V, CAT IV 600V
  • IEC 61010-1, IEC 61010-2-031.
  • Operating Range: Operating temperature range from 14°F to 122°F.
  • Calibration: Calibration certificate included.
