Energy Logger, 1734 Series, 3-Phase, Power Quality Analyzer, 5 Current/4 Voltage Channels MPN:FLUKE-1734/EUS
Free Shipping
In Stock
The Fluke Power Quality Analyzer is a comprehensive tool for monitoring and analyzing electrical energy in real-time. With its 5 current channels and 4 voltage channels, it can measure up to 1,500 A of AC current and provide detailed insights into power quality. Ideal for use in industrial settings, the analyzer helps identify energy waste, optimize energy usage, and ensure compliance with regulatory standards. Its advanced features, including Wi-Fi connectivity and Fluke Connect capabilities, enable seamless data transfer and analysis. Perfect for energy auditors, facility managers, and engineers, this analyzer streamlines energy monitoring and management.
Top product features:
- Energy Logger function allows for the recording of energy data
- Current accuracy of +/-0.01 percent enables precise measurements
- Four voltage channels provide comprehensive power analysis capabilities
Top product applications:
- Power monitoring and analysis in industrial settings
- Monitoring and troubleshooting electrical issues in commercial buildings
- Testing and verifying the performance of electrical systems in data centers
The FLUKE-1734/EUS is an energy logger and power quality analyzer for measuring and recording electrical parameters in single-phase, split-phase, and three-phase systems. It supports data logging, peak capture, and harmonic capture through the 50th harmonic, making it suitable for monitoring power usage, load conditions, and power quality trends. The unit features a color LCD touch screen with 480 x 272 resolution, onboard 2 GB storage, and communication options that include Bluetooth, USB-A, USB-Mini, and Wi-Fi.
Key Features of the FLUKE-1734/EUS Power Quality Analyzer:
- Display: Color LCD touch screen with 480 x 272 resolution for viewing measurements and logged data.
- Phase Compatibility: Works with single-phase, split-phase, and three-phase systems.
- Channels: 5 current channels and 4 voltage channels support multi-parameter measurement.
- Measurement Range: Up to 1,500 A AC, 1000 A DC, 1500 V AC, and 1000 V DC.
- Accuracy: Current accuracy of +/-0.01% and voltage accuracy of +/-0.2%.
- Power and Analysis: Measures power factor from -1 to 1, captures harmonics through the 50th, and includes peak capture with a 200 nS minimum transient duration.
- Sampling and Response: 10.24 kHz sampling rate and 5 kHz AC response.
- Connectivity and Storage: Includes Bluetooth, USB-A, USB-Mini, Wi-Fi, and 2 GB storage.
- Current Capability: Kit current capability from 1 to 1,500 A.
- Ratings: IP50
- CAT III 1000V, CAT IV 600V, IEC 61010-1, IEC 61010-2-031.
- Included: Energy Logger with Fluke Connect and calibration certificate.
- Operating Temperature: 14 to 122 degrees F.
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.10
- Package Width: 11.60
- Package Height: 9.70
- Package Weight: 10.60
