Handheld Pressure Calibrator, 718 Series, -12 to 100 psi, Internal Pump, 0 to 24 mA DC MPN:FLUKE 718 100G

• The FLUKE 718 100G is a handheld pressure calibrator for measuring and sourcing pressure and DC current in process calibration work. It measures internal pressure from -12 to 100 psi, generates pressure from 0 to 100 psi with an internal electric pump, and supports 0 to 24 mA DC current measurement and sourcing. A multiline LCD displays pressure in multiple units including psi, bar, kPa, mbar, in Hg, and in wc, and the unit can also be used with Fluke 750P Series pressure modules for expanded pressure ranges.

  Key Features of the FLUKE 718 100G Pressure Calibrator:


  • Pressure range: Measures internal pressure from -12 to 100 psi and generates pressure from 0 to 100 psi.
  • Pressure accuracy: Pressure measurement accuracy is +/-0.025% full scale
  • internal pressure range accuracy is +/-0.05% full scale.
  • Current capability: Measures and sources 0 to 24 mA DC for loop checking and calibration tasks.
  • Loop supply: Provides 24 V DC loop supply.
  • Display: Multiline LCD with pressure units including bar, cm wc, in Hg, in wc, kg/sq cm, kPa, mbar, mm Hg, and psi.
  • External module compatibility: Works with 750P Series pressure modules across 50 ranges, covering 1 in wc to 10,000 psi.
  • Power source: Powered by two 9V alkaline batteries
  • batteries are included.
  • Included accessories: Supplied with AC175 alligator clips and TL75 test leads.
  • Calibration certificate: Includes NIST calibration certificate.
