Handheld Pressure Calibrator, 3130-G2M Series, -12 to 300 psi, HART, Internal Pump MPN:3130-G2M
Free Shipping
In Stock
The Fluke Pressure Calibrator is a handheld, high-precision instrument designed for pressure calibration and measurement in a variety of industries. Its internal electric pump pressure source generates pressure up to 300 psi, while its measurement functions include mA DC, pressure, and VDC. The calibrator is also equipped with an internal pressure measurement range of 0 to 300 psi and can be expanded to -15 psi to 5000 psi with external modules. Ideal for use in calibration labs, field service, and industrial settings, the Fluke Pressure Calibrator provides accurate and reliable measurements, ensuring compliance with industry standards such as EN61326:2006 Annex A.
Top product features:
- Internal Electric Pump Pressure Source
- Internally Generated Pressure Range -12 to 300 psi
- Multiline LCD Display
Top product applications:
- Pressure calibration for industrial equipment
- Calibration of pressure sensors in oil and gas applications
- Measurement of pressure in HVAC systems
The FLUKE 3130-G2M is a handheld pressure calibrator with an internal electric pump and an internal pressure measurement range of 0 to 300 psi. It measures pressure, DC current, and DC voltage, and it can source pressure, DC current, and DC voltage. With HART communication, loop supply voltage, and support for external 700P Series pressure modules, it is used for pressure calibration and related process signal verification in the field or shop.
Key Features of the FLUKE 3130-G2M Pressure Calibrator:
- Internal pressure range: Measures 0 to 300 psi, with internally generated pressure from -12 to 300 psi.
- Pressure accuracy: 0.025% of reading ±0.01% full scale.
- Pressure units: Displays and measures in psi, bar, kPa, and MPa.
- Expanded pressure capability: Supports 700P Series pressure modules for external ranges from -15 psi to 5000 psi.
- Electrical measurement functions: Measures 0 to 24 mA DC and 0 to 30 V DC.
- Current sourcing: Sources 4 to 24 mA DC, with a listed source current range of 0 to 24 mA.
- Loop supply: 24 V DC loop supply for transmitter work.
- Display and interface: Multiline LCD display with RS-232 interface and HART communication protocol.
- Power and included accessories: Powered by an internal rechargeable battery or universal AC adapter
- includes batteries, test leads, and a universal AC adapter.
- Calibration certificate: NIST traceable calibration certificate included.
- Standard: EN61326:2006 Annex A.
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.00
- Package Width: 7.25
- Package Height: 12.63
- Package Weight: 15.00
