Noncontact Ultrasonic Level Sensor, 3.9"W MPN:LR15-0010-20
Noncontact Ultrasonic Level Sensor, 3.9"W
Accurately measure liquid levels in a wide range of applications with the Noncontact Ultrasonic Level Sensor. Suitable for use with chemicals, oil, wastewater, and water, this sensor provides precise readings of up to 1,180.8 inches with an accuracy of +/-3 mm. Its noncontact design makes it ideal for applications where contamination is a concern, and its wide operating temperature range (-76°F to 302°F) and pressure range (up to 150 psi) ensure reliable performance in harsh environments. Perfect for use in industries such as manufacturing, wastewater treatment, and chemical processing, this sensor offers a reliable and accurate solution for level measurement needs.
Top product features:
- Noncontact ultrasonic sensing technology allows for accurate measurement without physical contact with the media.
- The sensor has a wide measurement range of up to 1,180.8 inches.
- The sensor operates at a frequency of 26 kHz, providing high spatial resolution of 0.118 inches.
Top product applications:
- Level monitoring in chemical tanks
- Monitoring oil levels in storage containers
- Measuring wastewater levels in treatment facilities
Noncontact Ultrasonic Level Sensor, For Media Type Chemicals, Oil, Wastewater, Water, Antenna Diameter 3 7/8 in, Range 1,180.8 in, Connection Size 1 1/2 in, Connection Type NPT, Accuracy +/-3 mm, Voltage - Maximum 26V DC, Dead Band 12 in, Beam Angle 18 Degrees , Operating Frequency 26 kHz, Spatial Resolution 0.118 in, Operating Pressure - Maximum 150 psi, Media Temperature - Minimum -76 Degrees F, Media Temperature - Maximum 302 Degrees F, Output Wire Configuration 2-Wire
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 20 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.10
- Package Width: 8.40
- Package Height: 8.60
- Package Weight: 6.40
Product info last updated on February 2, 2026 3:58pm UTC
Category: Pump Controls
