Noncontact Ultrasonic Level Sensor, 3.9"W MPN:LR20-0310-40
Noncontact Ultrasonic Level Sensor, 3.9"W
Monitor liquid levels in chemical, oil, wastewater, and water applications with the Flowline Noncontact Ultrasonic Level Sensor. This reliable device offers high accuracy, with a +/-3 mm reading range of up to 787.2 inches. Its noncontact design and 8-degree beam angle ensure precise measurements without interfering with the process. Suitable for temperatures from -76 to 302 degrees Fahrenheit and pressures up to 72 psi, this sensor is ideal for industrial and commercial settings. Its 2-wire output and compact design make it easy to integrate into existing systems, providing real-time level monitoring and process control.
Top product features:
- Noncontact measurement provides accurate level readings without physical contact with the media.
- Operating frequency of 26 kHz enables precise ultrasonic level detection.
- Spatial resolution of 0.118 in allows for detailed measurement of liquid levels.
Top product applications:
- Chemical tank level monitoring
- Wastewater treatment plant level monitoring
- Oil storage tank level measurement
Noncontact Ultrasonic Level Sensor, For Media Type Chemicals, Oil, Wastewater, Water, Antenna Diameter 3 7/8 in, Range 787.2 in, Connection Size 1/2 in, Connection Type NPT, Accuracy +/-3 mm, Voltage - Maximum 26V DC, Dead Band 12 in, Beam Angle 8 Degrees , Operating Frequency 26 kHz, Spatial Resolution 0.118 in, Operating Pressure - Maximum 72 psi, Media Temperature - Minimum -76 Degrees F, Media Temperature - Maximum 302 Degrees F, Output Wire Configuration 2-Wire
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 20 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.80
- Package Width: 10.40
- Package Height: 12.50
- Package Weight: 17.30
Product info last updated on April 3, 2026 11:03am UTC
Category: Pump Controls
