Sprial Wound Metal Gasket, 8 In, 316SS MPN:CG
Sprial Wound Metal Gasket, 8 In, 316SS
This Spiral Wound Metal Gasket is designed for use on ANSI Class 300 flanges with a pipe size of 8 inches, offering a reliable seal in high-temperature applications. The 316SS stainless steel spiral winding provides excellent corrosion resistance and durability, while the graphite filler material ensures a tight seal. Suitable for use in a wide range of industries, including oil and gas, chemical processing, and power generation, this gasket can withstand temperatures from -400°F to 842°F, making it an ideal solution for demanding applications. Its compact design and easy installation make it a convenient choice for maintenance and repairs.
Top product features:
- Spiral winding material provides high temperature resistance up to 842 Degrees F.
- Graphite filler material enhances sealing performance.
- Stainless steel grade 316L spiral winding material resists corrosion.
Top product applications:
- High-pressure applications in the chemical industry
- Pulp and paper mill equipment
- Power generation plants
Spiral Wound Flange Gasket, For Flange ANSI Class 300, For Pipe Size 8 in, Inside Diameter 9 3/16 in, Outside Diameter 12 1/8 in, Thickness 3/16 in, Rim Stripe Color Gray, Outside Rim Color Green, Filler Material Graphite, Outer Ring Material Carbon Steel, Minimum Operating Temperature -400 Degrees F, Maximum Operating Temperature 842 Degrees F, Spiral Winding Material Stainless Steel, Spiral Winding Stainless Steel Grade 316L, Inner Ring Material None
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.20
- Package Width: 12.20
- Package Height: 0.30
- Package Weight: 1.45
Product info last updated on January 28, 2026 7:17pm UTC
Category: Sealing and Gasketing
