Spiral Wound Metal Gasket, 1-1/4In, 316SS MPN:CG
Spiral Wound Metal Gasket, 1-1/4In, 316SS
This Spiral Wound Metal Gasket is designed for use on ANSI Class 150 flanges, providing a reliable seal for 1 1/4 inch pipes. Made with a durable 316SS spiral winding and carbon steel outer ring, it can withstand extreme temperatures from -400°F to 842°F. The graphite filler material ensures a tight seal, while the stainless steel spiral winding resists corrosion. Suitable for use in chemical, oil and gas, and power generation industries, this gasket is a versatile solution for applications requiring high pressure and temperature resistance. Its compact size and lightweight design make it easy to install and handle.
Top product features:
- Spiral winding provides a flexible seal that adapts to changing pipe dimensions.
- The gasket is designed for use with ANSI Class 150 flanges, ensuring compatibility with standard flange configurations.
- The gasket's graphite filler material provides a high-temperature resistant seal, suitable for use in extreme temperature applications.
Top product applications:
- High-temperature flange sealing in chemical processing plants
- Pressure vessel flange sealing in oil and gas refineries
- Steam turbine flange sealing in power generation facilities
Spiral Wound Flange Gasket, For Flange ANSI Class 150, For Pipe Size 1 1/4 in, Inside Diameter 1 7/8 in, Outside Diameter 3 in, Thickness 3/16 in, Rim Stripe Color Gray, Outside Rim Color Green, Filler Material Graphite, Outer Ring Material Carbon Steel, Minimum Operating Temperature -400 Degrees F, Maximum Operating Temperature 842 Degrees F, Spiral Winding Material Stainless Steel, Spiral Winding Stainless Steel Grade 316L, Inner Ring Material None
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.00
- Package Width: 3.00
- Package Height: 0.30
- Package Weight: 0.15
Product info last updated on January 14, 2026 7:59pm UTC
Category: Sealing and Gasketing
