Spiral Wound Metal Gasket, 1 In, 316SS MPN:CG
Spiral Wound Metal Gasket, 1 In, 316SS
The Flexitallic Spiral Wound Metal Gasket is a high-performance solution for demanding applications. Designed for ANSI Class 300, 400, and 600 flanges, this gasket features a spiral wound construction with a stainless steel grade 316L winding, ensuring exceptional durability and resistance to extreme temperatures (-400°F to 842°F). The graphite filler material and carbon steel outer ring provide a secure seal, while the gray and green color coding ensures easy identification. Ideal for use in chemical processing, power generation, and other high-pressure industries, this gasket offers reliable performance and long-lasting service, minimizing downtime and maintenance costs.
Top product features:
- Spiral winding provides a tight seal around the flange.
- The gasket is designed for use with ANSI Class 300, 400, and 600 flanges.
- The gasket is suitable for high-temperature applications up to 842 Degrees F.
Top product applications:
- High Pressure Steam Applications
- Pulp and Paper Industry Equipment
- Oil and Gas Industry Piping Systems
Spiral Wound Flange Gasket, For Flange ANSI Class 300, 400, 600, For Pipe Size 1 in, Inside Diameter 1 1/4 in, Outside Diameter 2 7/8 in, Thickness 3/16 in, Rim Stripe Color Gray, Outside Rim Color Green, Filler Material Graphite, Outer Ring Material Carbon Steel, Minimum Operating Temperature -400 Degrees F, Maximum Operating Temperature 842 Degrees F, Spiral Winding Material Stainless Steel, Spiral Winding Stainless Steel Grade 316L, Inner Ring Material None
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.80
- Package Width: 2.80
- Package Height: 0.30
- Package Weight: 0.15
Product info last updated on February 4, 2026 1:07pm UTC
Category: Sealing and Gasketing
