Spiral Wound Metal Gasket, 3/4 In, 316SS MPN:CG
Spiral Wound Metal Gasket, 3/4 In, 316SS
This 316SS spiral wound metal gasket from Flexitallic is designed for use on ANSI Class 300, 400, and 600 flanges, making it suitable for a wide range of industrial applications, including chemical processing, power generation, and oil and gas production. Its excellent durability and resistance to extreme temperatures (-400°F to 842°F) ensure reliable performance in high-pressure and high-temperature environments. The graphite filler material provides excellent sealing properties, while the stainless steel 316L spiral winding ensures resistance to corrosion and chemical degradation. Its compact design and ease of installation make it an ideal choice for pipe sizes 3/4 inches.
Top product features:
- Spiral winding material is made from stainless steel for corrosion resistance.
- The gasket has a graphite filler material for sealing and insulation properties.
- The spiral winding material is stainless steel grade 316L, which provides high temperature resistance.
Top product applications:
- High-pressure chemical processing
- Pulp and paper production
- Power generation
Spiral Wound Flange Gasket, For Flange ANSI Class 300, 400, 600, For Pipe Size 3/4 in, Inside Diameter 1 in, Outside Diameter 2 5/8 in, Thickness 3/16 in, Rim Stripe Color Gray, Outside Rim Color Green, Filler Material Graphite, Outer Ring Material Carbon Steel, Minimum Operating Temperature -400 Degrees F, Maximum Operating Temperature 842 Degrees F, Spiral Winding Material Stainless Steel, Spiral Winding Stainless Steel Grade 316L, Inner Ring Material None
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.60
- Package Width: 2.60
- Package Height: 0.20
- Package Weight: 0.10
Product info last updated on May 12, 2026 5:05pm UTC
Category: Sealing and Gasketing
