Spiral Wound Metal Gasket, 2-1/2In, 316SS MPN:CG
Spiral Wound Metal Gasket, 2-1/2In, 316SS
This Spiral Wound Metal Gasket from Flexitallic is designed for use on flanges with an ANSI Class 150 rating, making it suitable for a variety of industrial applications. The gasket features a spiral wound design with a stainless steel core and a carbon steel outer ring, providing excellent sealing performance in extreme temperatures. Its use of graphite as a filler material enhances its compressibility and resistance to corrosion. With a temperature range of -400°F to 842°F, this gasket is ideal for use in oil and gas, chemical processing, and power generation industries where high performance and reliability are critical.
Top product features:
- Spiral winding provides a tight seal for high-pressure applications.
- The gasket is designed for use with ANSI Class 150 flanges.
- The gasket is constructed with a graphite filler material for optimal sealing performance.
Top product applications:
- High Pressure Valve Seals
- Chemical Processing Equipment Gaskets
- Power Plant Flange Gaskets
Spiral Wound Flange Gasket, For Flange ANSI Class 150, For Pipe Size 2 1/2 in, Inside Diameter 3 1/4 in, Outside Diameter 4 7/8 in, Thickness 3/16 in, Rim Stripe Color Gray, Outside Rim Color Green, Filler Material Graphite, Outer Ring Material Carbon Steel, Minimum Operating Temperature -400 Degrees F, Maximum Operating Temperature 842 Degrees F, Spiral Winding Material Stainless Steel, Spiral Winding Stainless Steel Grade 316L, Inner Ring Material None
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.80
- Package Width: 4.80
- Package Height: 0.30
- Package Weight: 0.30
Product info last updated on February 3, 2026 2:21am UTC
Category: Sealing and Gasketing
