Spiral Wound Metal Gasket, 3 In, 316SS MPN:CG
Spiral Wound Metal Gasket, 3 In, 316SS
Protect your industrial equipment with the Flexitallic Spiral Wound Metal Gasket, designed for reliable sealing in harsh environments. Suitable for flanges of ANSI Class 300, 400, and 600, this gasket features a 3/16-inch thickness and 316L stainless steel spiral winding for maximum durability. With a temperature range of -400°F to 842°F, it can withstand extreme conditions. The graphite filler material ensures a tight seal, while the carbon steel outer ring provides added strength. Ideal for use in chemical processing, oil and gas, and power generation industries, this gasket provides long-lasting performance and peace of mind.
Top product features:
- Spiral winding material provides high temperature resistance up to 842 Degrees F
- Graphite filler material enhances sealing performance
- Spiral wound construction allows for tight sealing around flange irregularities
Top product applications:
- High-temperature pipe connections
- High-pressure vessel flange sealing
- Industrial pipe flange connections
Spiral Wound Flange Gasket, For Flange ANSI Class 300, 400, 600, For Pipe Size 3 in, Inside Diameter 4 in, Outside Diameter 5 7/8 in, Thickness 3/16 in, Rim Stripe Color Gray, Outside Rim Color Green, Filler Material Graphite, Outer Ring Material Carbon Steel, Minimum Operating Temperature -400 Degrees F, Maximum Operating Temperature 842 Degrees F, Spiral Winding Material Stainless Steel, Spiral Winding Stainless Steel Grade 316L, Inner Ring Material None
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.80
- Package Width: 5.80
- Package Height: 0.30
- Package Weight: 0.45
Product info last updated on March 25, 2026 2:20pm UTC
Category: Sealing and Gasketing
