Metal Gasket, 3/4 in. In, 2-1/2 in. Out MPN:005090008
Metal Gasket, 3/4 in. In, 2-1/2 in. Out
This high-performance metal gasket from Flexitallic is designed for demanding applications in the oil and gas, chemical, and power industries. Its spiral wound construction provides exceptional sealing capabilities, while its stainless steel winding and carbon steel outer ring ensure durability and resistance to extreme temperatures. Suitable for ANSI Class 900 flanges, this gasket meets the highest standards for performance and safety. Its compact size and versatility make it an ideal choice for a wide range of applications, including pipeline connections, valve seals, and equipment mounting. With a temperature range of -320°F to 842°F, it can withstand even the most challenging conditions.
Top product features:
- Spiral winding made from stainless steel provides resistance to corrosion and chemical attack.
- The gasket is designed to seal flanges of ANSI Class 900 and 1500, ensuring a secure and leak-free connection.
- The spiral wound design allows for compression and expansion, accommodating temperature changes and ensuring a tight seal.
Top product applications:
- Pressure vessel construction
- High-temperature pipe flanges
- Oil and gas industry applications
Spiral Wound Flange Gasket, For Flange ANSI Class 900, 1,500, For Pipe Size 1/2 in, Inside Diameter 3/4 in, Outside Diameter 2 1/2 in, Thickness 1/4 in, Rim Stripe Color Gray, Outer Ring Material Carbon Steel, Minimum Operating Temperature -320 Degrees F, Maximum Operating Temperature 842 Degrees F, Spiral Winding Material Stainless Steel, Spiral Winding Stainless Steel Grade 304, Inner Ring Stainless Steel Grade Not Applicable, Standards ASME B16.20, ASME/ANSI, System of Measurement Inch
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 2.50
- Package Height: 0.20
- Package Weight: 0.15
Product info last updated on February 24, 2026 11:41am UTC
Category: Sealing and Gasketing
