Multi-Tone Signal, Horn, Continuous, 24V AC/DC, 110 dB, Zinc Alloy, Gray, Conduit, Surface Mount MPN:5530M-24AQ
Free Shipping
In Stock
The Edwards Signaling Multi-Tone Signal is a reliable and versatile audible alarm solution for indoor and outdoor applications. Suitable for use in hazardous locations, including Division 2 areas, this 110 dB horn provides a continuous sound pattern to grab attention in high-noise environments. With a zinc alloy housing and operating temperature range of -40 to 151 degrees F, it can withstand harsh conditions. Easy to install with captive components and a surface mount design, this product is ideal for use in industrial settings, such as manufacturing facilities, warehouses, and construction sites, where clear communication is crucial for safety and productivity.
Top product features:
- Captive Components
- Continuous Sound Pattern
- 110 dB Sound Output
Top product applications:
- Industrial alarm systems for hazardous locations
- Emergency exit signaling systems
- Factory floor warning systems
The EDWARDS SIGNALING 5530M-24AQ is a surface-mount multi-tone signal with a horn-style audible output and continuous sound pattern. It operates on 24V AC/DC and produces up to 110 dB output for audible warning applications in locations rated for indoor or outdoor use. Includes a zinc alloy housing, conduit mounting option, wire-lead connection, and hazardous location ratings for Class I, Division 2 and Class II, Division 2 locations.
Key Features:
- Horn-style audible alarm with continuous sound pattern
- Sound output up to 110 dB
- minimum alarm volume rated at 95 dB at 1 m and 98 dB at 10 ft
- 24V AC/DC operation
- Current draw: 0.74 A at 24V DC and 1.3 A at 24V AC
- Wire-lead connection with wired power source
- Conduit and surface-mount installation
- Zinc alloy housing with gray finish
- Rated for indoor and outdoor use
- Hazardous location ratings: Class I, Division 2
- Class II, Division 2
- hazardous classes I, II, III
- Division 2
- NEMA 3R rating
- Operating temperature: -31°F to 104°F in hazardous locations
- -40°F to 151°F in non-hazardous locations
- Captive components
- no visual indicator
- no vibration
- cULus and UL Listed
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.00
- Package Width: 12.00
- Package Height: 10.60
- Package Weight: 12.25
