Bell, Bell, Continuous, 24V AC, 84 dB, Steel, Gray, Wall Mount MPN:340EX-6G5

• EDWARDS SIGNALING 340EX-6G5 is a wall-mounted vibrating bell for audible signaling. It operates on 24V AC and produces a continuous bell sound at 84 dB at 10 ft (94 dB maximum at 1 m). The gray steel housing is factory assembled and NEMA 4 rated for indoor installations where a bell-style audible alert is required.

  Key Features:

  • Audible alarm type: Bell with continuous sound pattern
  • Sound output: 84 dB at 10 ft
  • 94 dB maximum at 1 m
  • Operating voltage: 24V AC
  • Current draw: 0.21 A
  • Construction: Steel housing, gray finish
  • Mounting: Wall mount, surface mount
  • Connection type: Wire leads
  • Protection rating: NEMA 4
  • Features: Factory assembled
  • NEMA 4 rated
  • Hazardous location ratings: Class I, Division 1
  • Class I, Division 2
  • Class II, Division 1
  • Class II, Division 2
  • Hazardous class/division: I, II, III
  • 1, 2
  • Visual indicator type: None
  • Standards: UL Listed
  • Dimensions: 7 in. diameter
  • 5 in. depth
