Power Distribution Block, Open, 1 Pole, 380 A Copper, 600 V AC/DC MPN:16378-1
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0970444
Power Distribution Block, Open, 1 Pole, 380 A Copper, 600 V AC/DC
The Eaton Bussmann Power Distribution Block is a reliable and efficient solution for distributing power in a variety of applications. With a maximum current of 380 A and a maximum voltage of 600 V AC/DC, this block is suitable for use in industrial and commercial settings. Its open design allows for easy access and installation, and the 1/4-20 x 1 in stud size on the load side makes it easy to connect and disconnect wires. Ideal for use in power distribution systems, the Power Distribution Block is a versatile and reliable choice for a wide range of applications.
Top product features:
- Power Distribution Block has a maximum current rating of 380 A for copper conductors.
- Power Distribution Block supports line connections for copper wire sizes ranging from 6 AWG to 500 kcmil.
- Power Distribution Block has a load connection on the second pole, with a stud size of 1/4-20 x 1 in.
Top product applications:
- Electrical Panel Installations
- Commercial and Industrial Power Distribution Systems
- High-Ampacity Power Distribution in Manufacturing Facilities
Power Distribution Block, For Conductor Material Aluminum, Copper, Line Connections/Pole 1, Line Side Stud Size Not Applicable, For Line Copper Wire Size - Minimum 6 AWG, For Line Copper Wire Size - Maximum 500 kcmil, Load Connections/Pole 2, Load Side Stud Size 1/4-20 x 1 in, For Load Copper Wire Size - Maximum Not Applicable, Maximum Current - Copper Conductor 380 A, Maximum Voltage 600 V, Mounting Type Surface, Number of Poles 1, Overall Depth 3.22 in, Overall Length 3.98 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 180 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.30
- Package Width: 3.70
- Package Height: 2.60
- Package Weight: 0.80
Product info last updated on January 15, 2026 5:30am UTC
Category: Electrical Connectors
