Horn, Horn, Continuous/Pulse, 12V, 24V, 80 dBA, Plastic, White, Ceiling Mount MPN:ELHNRC
Free Shipping
In Stock
This versatile audible alarm horn from Eaton is designed for indoor use, providing a reliable and effective warning system. With a sound pattern of continuous or pulse, it can be used in a variety of applications, including industrial, commercial, and residential settings. The horn's 80 dBA sound level ensures that it can be heard clearly, even in noisy environments. Its compact size and ceiling mount design make it easy to install and discreetly integrate into any space. Ideal for use in areas where visual indicators are not necessary, this horn provides a simple and effective solution for alerting individuals to potential hazards or issues.
Top product features:
- It produces an 80 dBA sound pattern that can be set to continuous or pulse.
- It is designed for ceiling mounting.
- It operates within a temperature range of 32 to 122 Degrees F.
Top product applications:
- Fire Alarm System
- Emergency Evacuation System
- Industrial Automation Notification System
The EATON ELHNRC is an indoor ceiling-mount horn for audible signaling. It produces an 80 dBA horn sound with continuous or pulse operation and is rated for 12V and 24V operation. The low-profile white plastic housing is designed for indoor ceiling-mount audible signaling applications.
Key Features:
- Audible alarm type: Horn with continuous and pulse sound patterns.
- Sound output: 80 dBA minimum at 10 ft.
- Voltage: 12V, 24V.
- Operating current: 0.086 A @ DC
- listed current draw values: 0.022 DC, 0.03 DC, 0.06 DC, 0.086 DC, 0.125 DC, 0.185 DC.
- Construction: White plastic housing with Lexan® lens material.
- Mounting: Surface mount for ceiling installation
- mounting plate and mounting hardware included.
- Design features: Low-profile design
- power rating: 5 W
- includes continuous T3 and T3/T4 temporal sound patterns.
- Operating temperature: 32°F to 122°F.
- Dimensions: 6.25 in. diameter, 1.8 in. height, 6.27 in. width, 1 5/16 in. overall depth.
- Location rating: Indoor.
- Standards: UL Listed, ULC Listed.
- Visual indicator type: No visual indicator.
Additional Information
- Country of Origin: RO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 7.00
- Package Height: 6.25
- Package Weight: 0.70
