Heavy Duty Limit Switch, Wobble Stick, 2NC/2NO, 10A at 600V AC, Actuator Location: Top MPN:E50BW1
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5233024
Heavy Duty Limit Switch, Wobble Stick, 2NC/2NO, 10A at 600V AC, Actuator Location: Top
The Eaton Heavy Duty Limit Switch with Wobble Stick actuator is a reliable and versatile solution for a wide range of applications. Suitable for use in harsh environments, this switch features a rugged design with a NEMA rating of 3, 3S, 4X, and 6P, and an IP67 rating for protection against dust and water. With a 10A rating at 600V AC and a 2NC/2NO contact form, this switch is ideal for use in industrial control systems, machinery, and automation. Its compact size and low operating force make it easy to integrate into new or existing systems, providing reliable and efficient performance.
Top product features:
- 2NC/2NO contact form allows for two normally closed and two normally open positions
- Wobble stick actuator provides 10 degrees of operating travel for precise adjustment
- IP67 rating ensures the product is dustproof and can withstand temporary submersion in water
Top product applications:
- Industrial conveyor systems
- Machine tool control and monitoring
- Automated manufacturing and assembly lines
Plug-In Limit Switch, Actuator Style Wobble Stick, Actuator Location Top, Actuator Length 1.54 in, Contact Form 2NC/2NO, Amps 10, Voltage Rating 600VAC, Travel Operating Travel 10 Degrees , Reset Travel 6 Degrees , Total Travel 15 Degrees , Movement Rotary, Operating Force 2 lbf, NEMA Rating 3, 3S, 4X, 6P, IP Rating IP67, Standards CE, CSA, UL Listed
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 17 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.40
- Package Width: 4.40
- Package Height: 2.90
- Package Weight: 1.00
Product info last updated on February 2, 2026 8:42am UTC
Category: Industrial Electrical Controls and Automation
