Circuit Breaker, PDG Series, 90A, 2 Pole, 600V AC, 35kA at 480V AC, A Curve MPN:PDG22G0090TFFL
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G500901842
Circuit Breaker, PDG Series, 90A, 2 Pole, 600V AC, 35kA at 480V AC, A Curve
Protect your electrical system with the reliable PDG Series Circuit Breaker from Eaton. This 90A, 2-pole circuit breaker is designed for use in a variety of applications, including commercial and industrial settings. With a maximum air rating of 35kA at 480V AC, it provides superior protection against electrical faults and overloads. The thermal magnetic trip type ensures quick and reliable disconnection in case of an emergency. Suitable for use in phase three, three-phase systems, this circuit breaker is a must-have for any electrical installation. Its compact size and standard terminal connection make it easy to integrate into your existing electrical system.
Top product features:
- Breaks circuit overload with a maximum interrupting capacity of 35kA at 480V AC
- Protects against both thermal and magnetic faults with a thermal magnetic trip type
- Connects to a 3-phase electrical system with an AB phase connection
Top product applications:
- Main Power Distribution Panels
- Commercial and Industrial Electrical Systems
- Heavy-Duty Industrial Machinery Protection
Circuit Breaker, 90 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 35 kA at 480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Terminal Connection Standard Terminals Load Only, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection AB, Frame Size 225A/Frame 2, Height 6 in, Width 4.11 in, Depth 3.5 in, Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG, Max. Operating Temp. 158 Degrees F, Min. Operating Temp. -4 Degrees F
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.00
- Package Width: 6.00
- Package Height: 4.00
- Package Weight: 5.00
Product info last updated on March 4, 2026 12:08am UTC
Category: Circuit Protection
