Molded Case Circuit Breaker, EHD Series, 20A, 1 Pole, 277V AC, 18kA at 240V AC MPN:EHD1020
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3783477
Molded Case Circuit Breaker, EHD Series, 20A, 1 Pole, 277V AC, 18kA at 240V AC
Eaton's EHD Series Molded Case Circuit Breaker is a reliable and efficient solution for industrial control systems. Designed for use with Allen Bradley, Eaton, and Rockwell Automation enclosures, this circuit breaker provides high amp trip settings of 100A and low amp settings of 10A, ensuring optimal protection for your equipment. With a maximum AIR rating of 18kA at 240V AC, it can handle demanding applications. Suitable for use in switchboards, control panels, and other industrial settings, the EHD Series circuit breaker offers thermal magnetic tripping and instantaneous trip fixed functionality, providing peace of mind and reliable performance.
Top product features:
- Trip Type Thermal Magnetic
- High Amp Trip Setting 100 A
- Low Amp Trip Setting 10 A
Top product applications:
- Allen Bradley MCC
- Eaton MCC Eaton
- Rockwell Automation Enclosed Control
Molded Case Circuit Breaker, 20 A Amps, AC Voltage Rating 277V AC, Max. AIR Rating 18kA at 240V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series EHD, High Amp Trip Setting 100 A, Low Amp Trip Setting 10 A, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating 125V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Fixed, Phase Connection A, Frame Size 100A/F
Additional Information
- Country of Origin: DO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.40
- Package Width: 4.60
- Package Height: 2.00
- Package Weight: 1.58
Product info last updated on February 24, 2026 10:39am UTC
Category: Circuit Protection
