Molded Case Circuit Breaker, EHD Series, 20A, 2 Pole, 480V AC, 18kA at 240V AC MPN:EHD2020
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3783459
Molded Case Circuit Breaker, EHD Series, 20A, 2 Pole, 480V AC, 18kA at 240V AC
The Eaton EHD Series 20A Molded Case Circuit Breaker is a reliable and efficient solution for a variety of applications, including industrial control panels, switchboards, and motor control centers. With a high amp trip setting of 100A and low amp trip setting of 10A, this circuit breaker provides precise control and protection for your electrical system. Compatible with leading brands such as Allen Bradley, Rockwell Automation, and Westinghouse, this product is ideal for use in enclosed control panels, motor control centers, and switchboards. Its thermal magnetic trip type and instantaneous trip fixed feature ensure safe and reliable operation.
Top product features:
- Molded case circuit breaker provides overcurrent protection for electrical systems
- Trip setting allows for adjustable sensitivity to prevent circuit overload
- Thermal magnetic trip type combines temperature and magnetic sensing for enhanced fault detection
Top product applications:
- Allen Bradley MCC
- Eaton MCC
- Rockwell Automation Enclosed Control
Molded Case Circuit Breaker, 20 A Amps, AC Voltage Rating 480V AC, Max. AIR Rating 18kA at 240V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series EHD, High Amp Trip Setting 100 A, Low Amp Trip Setting 10 A, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating 250V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Fixed, Phase Connection ABC
Additional Information
- Country of Origin: DO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.50
- Package Width: 3.50
- Package Height: 5.30
- Package Weight: 2.90
Product info last updated on January 14, 2026 11:15am UTC
Category: Circuit Protection
