Molded Case Circuit Breaker, ED Series, 100A, 3 Pole, 240V AC, 65kA at 240V AC MPN:ED3100
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3731835
Molded Case Circuit Breaker, ED Series, 100A, 3 Pole, 240V AC, 65kA at 240V AC
Eaton's ED Series Molded Case Circuit Breaker is a reliable and high-performance solution for industrial applications. Designed for use with Allen Bradley, Eaton, and Rockwell Automation MCCs, this 100A, 3-pole circuit breaker provides maximum protection for your electrical system. With a high amp trip setting of 225A and low amp trip setting of 15A, it ensures safe and efficient operation. Suitable for use in switchboards and enclosed controls, this circuit breaker is ideal for applications requiring high voltage and current ratings. Its thermal magnetic trip type and instantaneous trip fixed feature provide added protection against electrical faults and overloads.
Top product features:
- Molded case design provides a compact and ruggedized enclosure for the circuit breaker
- Three-pole configuration allows for simultaneous control of three phases of a circuit
- Instantaneous trip feature provides fast and automatic shutdown in case of an overload or short circuit
Top product applications:
- Allen Bradley MCC
- Eaton MCC Eaton
- Rockwell Automation Enclosed Control
Molded Case Circuit Breaker, 100 A Amps, AC Voltage Rating 240V AC, Max. AIR Rating 65kA at 240V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series ED, High Amp Trip Setting 225 A, Low Amp Trip Setting 15 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 125V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 225A/F
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.50
- Package Width: 5.00
- Package Height: 4.80
- Package Weight: 4.40
Product info last updated on March 17, 2026 4:48pm UTC
Category: Circuit Protection
