Molded Case Circuit Breaker, EHD Series, 25A, 1 Pole, 277V AC, 18kA at 240V AC MPN:EHD1025
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3731765
Molded Case Circuit Breaker, EHD Series, 25A, 1 Pole, 277V AC, 18kA at 240V AC
Protect your electrical systems with the Eaton EHD Series Molded Case Circuit Breaker, designed for use with Allen Bradley, Eaton, Rockwell Automation, and Westinghouse control systems. This 25A, 1-pole circuit breaker provides reliable protection against overloads and short circuits, with a high amp trip setting of 100A and low amp trip setting of 15A. Suitable for applications in enclosed control, switchboard, and MCC settings, it offers a high level of safety and reliability. With its thermal magnetic trip type and instantaneous trip fixed feature, this circuit breaker ensures seamless operation and minimal downtime.
Top product features:
- Molded case design provides a compact and durable enclosure for the circuit breaker.
- Thermal magnetic trip type allows for reliable and sensitive detection of overloads and short circuits.
- Single-phase connection and instantaneous trip feature enable fast and efficient protection of circuits.
Top product applications:
- Allen Bradley MCC
- Eaton MCC Eaton
- Rockwell Automation Enclosed Control
Molded Case Circuit Breaker, 25 A Amps, AC Voltage Rating 277V AC, Max. AIR Rating 18kA at 240V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series EHD, High Amp Trip Setting 100 A, Low Amp Trip Setting 15 A, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating 125V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Fixed, Phase Connection A, Frame Size 100A/F
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 13 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.60
- Package Width: 4.50
- Package Height: 2.10
- Package Weight: 1.45
Product info last updated on February 24, 2026 8:34am UTC
Category: Circuit Protection
