Molded Case Circuit Breaker, EHD Series, 20A, 3 Pole, 480V AC, 18kA at 240V AC MPN:EHD3020
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3731640
Molded Case Circuit Breaker, EHD Series, 20A, 3 Pole, 480V AC, 18kA at 240V AC
Eaton's EHD Series Molded Case Circuit Breaker is a reliable and efficient solution for industrial applications. Suitable for use with Allen Bradley, Eaton, Rockwell Automation, and Westinghouse control systems, this circuit breaker provides high amp trip settings of 100A and low amp trip settings of 15A, ensuring safe and precise control of electrical currents. Its 18kA at 240V AC rating and 3-pole design make it ideal for switchboards and enclosed control applications. With a compact frame size of 100A/F, this circuit breaker is perfect for space-constrained environments, offering a reliable and cost-effective solution for a wide range of industrial applications.
Top product features:
- Three pole design allows for simultaneous control of three separate electrical circuits
- Thermal magnetic trip type provides enhanced protection against overloads and short circuits
- Instantaneous trip fixed feature enables fast and reliable disconnection in the event of a fault
Top product applications:
- Allen Bradley MCC
- Eaton MCC Eaton
- Rockwell Automation Enclosed Control
Molded Case Circuit Breaker, 20 A Amps, AC Voltage Rating 480V AC, Max. AIR Rating 18kA at 240V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series EHD, High Amp Trip Setting 100 A, Low Amp Trip Setting 15 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 100A/F
Additional Information
- Country of Origin: DO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.50
- Package Width: 5.00
- Package Height: 5.00
- Package Weight: 4.17
Product info last updated on February 12, 2026 11:12pm UTC
Category: Circuit Protection
