Molded Case Circuit Breaker, EHD Series, 30A, 3 Pole, 480V AC, 18kA at 240V AC MPN:EHD3030
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3731625
Molded Case Circuit Breaker, EHD Series, 30A, 3 Pole, 480V AC, 18kA at 240V AC
The Eaton EHD Series Molded Case Circuit Breaker is a reliable and efficient solution for protecting high-amperage electrical circuits. Designed for use with Allen Bradley, Eaton, and Rockwell Automation enclosures, this 3-pole circuit breaker is rated for 30A and 480V AC, with a maximum air rating of 18kA at 240V AC. Its high amp trip setting of 100A and low amp trip setting of 10A provide flexibility for various applications. Ideal for use in switchboards, control panels, and industrial settings, this circuit breaker offers thermal magnetic protection and instantaneous trip functionality, ensuring safe and reliable operation.
Top product features:
- Trip Type Thermal Magnetic, allowing for reliable protection against both thermal and magnetic faults.
- Instantaneous Trip Fixed, providing rapid and consistent response to overcurrent conditions.
- High Amp Trip Setting 100 A, enabling the circuit breaker to detect and interrupt high-amplitude faults before they cause damage.
Top product applications:
- Allen Bradley MCC
- Eaton MCC
- Rockwell Automation Enclosed Control
Molded Case Circuit Breaker, 30 A Amps, AC Voltage Rating 480V AC, Max. AIR Rating 18kA at 240V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series EHD, High Amp Trip Setting 100 A, Low Amp Trip Setting 10 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 100A/F
Additional Information
- Country of Origin: DO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.70
- Package Width: 5.10
- Package Height: 5.00
- Package Weight: 4.35
Product info last updated on February 7, 2026 3:30pm UTC
Category: Circuit Protection
