Miniature Circuit Breaker, GHB Series, 100A, 3 Pole, 277/480V AC, 14kA at 277/480V AC MPN:GHB3100
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3731135
Miniature Circuit Breaker, GHB Series, 100A, 3 Pole, 277/480V AC, 14kA at 277/480V AC
Protect your electrical system with the Eaton GHB Series 100A 3-Pole Miniature Circuit Breaker. Designed for use with Eaton Powerline Panelboards, this reliable device safeguards against overloads and short circuits, ensuring a safe and efficient electrical supply. Its compact size and bolt-on mounting style make it ideal for a variety of applications, including commercial and industrial settings. With a maximum AIR rating of 14kA at 277/480V AC, this circuit breaker provides robust protection against electrical surges and faults. Its easy-to-use toggle actuator and screw clamp terminal connections make it a convenient and efficient solution for your electrical needs.
Top product features:
- 100A current rating provides sufficient power for heavy-duty applications
- Three-pole design allows for independent control of three phases
- 14kA short-circuit interrupting rating ensures safe and reliable operation
Top product applications:
- Main electrical panel for a commercial building
- Residential electrical panel for a single-family home
- Industrial electrical panel for a manufacturing facility
Miniature Circuit Breaker, Amps 100 A, AC Voltage Rating 277/480V AC, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 125/250V DC, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series 1A, Phase Three, Series GHB, Max. AIR Rating 14kA at 277/480V AC, For Use With Eaton Powerline Panelboards, Terminal Connection Screw Clamp, Frame Size 100/GHB, Length 4 in, Width 3 in, Depth 2.63 in, Min. Operating Temp. -4 Degrees F
Additional Information
- Country of Origin: DO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.70
- Package Width: 3.80
- Package Height: 4.20
- Package Weight: 1.73
Product info last updated on February 8, 2026 2:51am UTC
Category: Circuit Protection
