480VAC Reversing Magnetic Contactor 3P 135A NEMA 4 MPN:CN55NN3C
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3719825
480VAC Reversing Magnetic Contactor 3P 135A NEMA 4
The Eaton 480VAC Reversing Magnetic Contactor is a robust and reliable solution for high-power applications. Designed for use in industrial settings, this 3P contactor can handle 135A of inductive current and supports 100hp at 480V AC. Its reversing capability allows for easy switching between forward and reverse operation, making it ideal for use in conveyor systems, pumps, and other machinery. With its NEMA 4 enclosure and screw terminal connections, this contactor is built for harsh environments and easy maintenance. Perfect for applications requiring high power and flexibility, this contactor is a valuable addition to any industrial control system.
Top product features:
- Reversing Capability: allows the contactor to switch direction of motor rotation
- Auxiliary Contact Form 1NO/1NC: provides two independent contact points for control circuit applications
- Screw Terminals: enables easy and secure connection to control wiring
Top product applications:
- Industrial Automation Systems
- Motor Control Centers
- Power Distribution Units
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size 4, Coil Voltage 440/480V AC, Number of Poles 3, Full Load Current - Inductive 135 A, Reversing Capability Reversing, Overall Height 9.11 in, Overall Width 7.05 in, Terminal Connection Type Screw Terminals, Frame Size N, Mounting Style Panel, Series Freedom, Number of Auxillary Contacts 2, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 50 hp, Horsepower @ Three Phase - 480V AC 100 hp
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 27 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.50
- Package Width: 16.10
- Package Height: 9.20
- Package Weight: 42.00
