24VAC Non-Reversing Magnetic Contactor 3P 135A NEMA 4 MPN:CN15NN3T
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3684615
24VAC Non-Reversing Magnetic Contactor 3P 135A NEMA 4
The Eaton 24VAC Non-Reversing Magnetic Contactor is a reliable and efficient solution for control applications. Designed for use in harsh environments, this contactor features a NEMA 4 enclosure rating and can withstand demanding conditions. With a high current rating of 135A, it can handle heavy loads and is ideal for use in three-phase systems. Suitable for applications such as motor control, lighting, and HVAC, this contactor provides a secure and efficient way to manage power. Its compact design and screw terminal connections make it easy to install and maintain, reducing downtime and increasing overall system performance.
Top product features:
- 24VAC operation allows for the contactor to be powered by a standard 24V AC supply.
- Three-pole design enables the contactor to control three-phase AC circuits.
- Non-reversing capability ensures the contactor only allows current to flow in one direction, preventing accidental reversal of motor rotation.
Top product applications:
- Motor Control Center for a 50 HP three-phase motor
- Industrial Automation for a 135A inductive load
- Power Distribution Panel for a 100 HP three-phase motor
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO, NEMA Enclosure Rating No Enclosure, NEMA Size 4, Coil Voltage 24V AC, Number of Poles 3, Full Load Current - Inductive 135 A, Reversing Capability Non-Reversing, Overall Height 9.11 in, Overall Width 7.05 in, Terminal Connection Type Screw Terminals, Frame Size N, Mounting Style Panel, Series Freedom, Number of Auxillary Contacts 1, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 50 hp, Horsepower @ Three Phase - 480V AC 100 hp
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 19 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.30
- Package Width: 9.60
- Package Height: 16.00
- Package Weight: 19.85
Product info last updated on February 9, 2026 4:29am UTC
Category: Industrial Electrical Controls and Automation
