240VAC Reversing Magnetic Contactor 3P 9A NEMA 00 MPN:CN55AN3BB
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3682061
240VAC Reversing Magnetic Contactor 3P 9A NEMA 00
The Eaton 240VAC Reversing Magnetic Contactor is a reliable and efficient solution for a wide range of industrial applications. Its reversing capability and 3-pole design make it ideal for use in conveyor systems, cranes, and other machinery that require frequent direction changes. With a full load current of 9A and a horsepower rating of 1 1/2 at 240V AC, this contactor can handle demanding tasks while minimizing energy consumption. Its compact size and screw terminal connections make it easy to integrate into existing systems, making it a versatile and valuable addition to any industrial setup.
Top product features:
- Reversing Capability to change the direction of motor rotation
- Auxiliary Contact Form 1NO/1NC to provide additional control or monitoring functions
- Screw Terminals for secure and easy electrical connections
Top product applications:
- Motor Control in Manufacturing Facilities
- Heavy-Duty Pump Control in Industrial Settings
- High-Power Fan Control in Commercial Buildings
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size 00, Coil Voltage 220/240V AC, Number of Poles 3, Full Load Current - Inductive 9 A, Reversing Capability Reversing, Overall Height 3.88 in, Overall Width 1.75 in, Terminal Connection Type Screw Terminals, Frame Size A, Mounting Style Panel, Series Freedom, Number of Auxillary Contacts 2, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 1 1/2 hp, Horsepower @ Three Phase - 480V AC 2 hp
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.80
- Package Width: 5.20
- Package Height: 5.10
- Package Weight: 2.65
Product info last updated on March 25, 2026 8:16am UTC
Category: Industrial Electrical Controls and Automation
