240VAC Reversing Magnetic Contactor 3P 135A NEMA 4 MPN:CN55NN3B
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3623891
240VAC Reversing Magnetic Contactor 3P 135A NEMA 4
Eaton's 240VAC Reversing Magnetic Contactor is a reliable and efficient solution for industrial applications. This 3P 135A contactor features a NEMA 4 enclosure rating and is designed for use in harsh environments. With reversing capability and a high horsepower rating of 50 hp at 240V AC and 100 hp at 480V AC, this contactor is ideal for use in high-torque applications such as pumps, fans, and conveyor systems. Its compact design and screw terminal connections make it easy to integrate into new or existing systems, providing reliable and efficient control in a wide range of industrial settings.
Top product features:
- Reversing Capability allows the contactor to switch direction of current flow
- Auxiliary Contact Form 1NO/1NC provides two separate contacts for control or monitoring purposes
- Screw Terminals allow for easy and secure connection of wires
Top product applications:
- High-power industrial motor control systems
- Industrial machinery control systems
- Large HVAC equipment control systems
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size 4, Coil Voltage 220/240V AC, Number of Poles 3, Full Load Current - Inductive 135 A, Reversing Capability Reversing, Overall Height 9.11 in, Overall Width 7.05 in, Terminal Connection Type Screw Terminals, Frame Size N, Mounting Style Panel, Series Freedom, Number of Auxillary Contacts 2, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 50 hp, Horsepower @ Three Phase - 480V AC 100 hp
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 14 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.50
- Package Width: 16.10
- Package Height: 9.40
- Package Weight: 42.00
Product info last updated on February 24, 2026 9:57am UTC
Category: Industrial Electrical Controls and Automation
