120VAC Reversing Magnetic Contactor 3P 45A NEMA 2
Eaton's 120VAC Reversing Magnetic Contactor is a reliable and efficient solution for controlling 3-phase AC motors in a variety of applications. Its reversing capability allows for easy direction control, making it ideal for use in conveyor systems, pumps, and fans. The contactor's 45A full load current rating and 15/25 hp three-phase capacity make it suitable for a range of horsepower requirements. Its compact design and screw terminal connections make it easy to install and integrate into existing systems. The contactor's high reliability and long lifespan reduce downtime and maintenance costs, making it a valuable addition to any industrial or commercial setting.
Top product features:
- Reversing Capability allows the contactor to change the direction of the motor's rotation
- Has a 3-pole configuration for 3-phase power applications
- Provides 2 auxiliary contacts for additional control and monitoring options
Top product applications:
- Motor Control Centers
- Industrial Automation Systems
- Power Distribution Systems
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size 2, Coil Voltage 110/120V AC, Number of Poles 3, Full Load Current - Inductive 45 A, Reversing Capability Reversing, Overall Height 5.05 in, Overall Width 2.56 in, Terminal Connection Type Screw Terminals, Frame Size G, Mounting Style Panel, Series Freedom, Number of Auxillary Contacts 2, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 15 hp, Horsepower @ Three Phase - 480V AC 25 hp
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 3 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.40
- Package Width: 6.50
- Package Height: 5.80
- Package Weight: 6.60
