IEC Magnetic Contactor, No Auxiliary Contacts, 24V DC, 4 P, Non-Reversing, Screw MPN:XTCF020B00TD
Free Shipping
In Stock
The Eaton XT IEC Magnetic Contactor is a reliable and efficient solution for a wide range of applications, including industrial automation, control systems, and power distribution. Its 4-pole, non-reversing design and 20A rating make it ideal for use in high-demand environments, while its 24V DC coil and embedded surge suppressor ensure safe and reliable operation. With certifications including UL Listed, CSA Certified, and IEC 60947, this contactor meets the highest standards of quality and safety, making it a trusted choice for applications in various industries, such as manufacturing, oil and gas, and renewable energy.
Top product features:
- Embedded Surge Suppressor provides protection against electrical surges and spikes
- Non-Reversing Action ensures the contactor only operates in one direction, preventing unintended power flow
- 4-Pole Configuration allows for the control of multiple circuits or loads with a single contactor
Top product applications:
- Control Panel Application
- This IEC magnetic contactor can be used in control panels for industrial automation systems, where it can control the flow of electrical current to various devices and machines.
- Motor Control Application
The Eaton XT IEC contactor is an IEC magnetic contactor (electrically operated switching device) rated for operation within the specified parameters. It is a 4-pole, non-reversing model with a 24 V DC coil and a 20 A rating. It uses screw terminals for wiring, includes an embedded surge suppressor, and has no enclosure (IP20). The unit mounts on DIN rails or panels and is rated for up to 690V AC. It carries standards including UL Listed
- CSA Certified
- IEC 60947
- EN 60947
- CE Marked
- RoHS.
- Amperage Rating: 20A
- - Coil Voltage: 24 V DC
- - Action: Non-Reversing
- - Poles: 4
- - Auxiliary Contacts: No
- - Contact Configuration: 0 NO, 0 NC
- - Maximum Voltage Rating: 690V AC
- - Embedded Surge Suppressor: Yes
- - Electrical Connection: Screw Terminals
- - Mounting Style: DIN Rail, Panel
- - Frame/Series: Frame B
- Series XT
- - Enclosure: The device does not include an enclosure
- ensure proper installation according to applicable standards.
- - IP Rating: IP20
- - Certifications: UL Listed
- CSA Certified
- IEC 60947
- EN 60947
- - Operating Temperature: -13°F to 122°F
- - Mechanical Durability: 10,000,000 cycles
- - Dimensions: 3 in W x 2 in H x 3 in D
- - Mounting Details: Mounting Hole Diameter 0.16 in
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.80
- Package Width: 2.00
- Package Height: 3.20
- Package Weight: 0.69
