IEC Magnetic Contactor, 1NO, 480V AC, 3 P, Non-Reversing, Screw MPN:XTCE012B10C

• The Eaton XT IEC contactor is an IEC magnetic contactor rated for operation within specified parameters. It is a 3-pole, non-reversing device with a 12 A rating and a coil voltage of 480 V AC. The unit includes 1 normally open auxiliary contact (1NO) and uses screw terminals for wiring. Suitable for DIN rail or panel mounting in frame size B

• rated for operation within specified voltage ranges. The XT series certifications include UL Listing, CSA Certification, IEC 60947 compliance, EN 60947 compliance, and CE marking.

  - Action: Non-Reversing

• - Poles: 3
• - Amperage rating: 12 A
• - Coil voltage: 480 V AC
• - Aux contact configuration: 1NO
• - Auxiliary contact form: 1NO
• - Electrical connection: Screw terminals
• - Mounting style: DIN Rail, Panel
• - Frame size/Series: Frame B / XT
• - Enclosure/IP: No Enclosure
• IP20
• - Maximum voltage rating: 690 V AC
• - Frequency: 50/60 Hz
• - Certifications: UL Listing
• CSA Certification
• IEC 60947 compliance
• EN 60947 compliance
• CE marking
• - Compliance: CE marking
• - Dimensions: Depth 2.95 in
• Height 1.77 in
• Width 3 in
• - Includes auxiliary contacts: Yes
