IEC Magnetic Contactor, No Auxiliary Contacts, 24V DC, 4 P, Non-Reversing, Screw MPN:XTCF160G00TD

• The Eaton XT IEC contactor is a four-pole, IEC magnetic switching device with a 24 V DC coil. It is non-reversing and rated for a current up to 160 A under specified conditions. The unit provides screw terminals, has no auxiliary contacts, and belongs to the XT series with frame size G. It is rated for operation within the specified voltage range of up to 690V AC, has an IP20 ingress protection rating without additional enclosure, and can be mounted on DIN rail or panel. Certifications include UL Listed

• CE Marked
• CSA Certified
• EN 60947
• IEC 60947
• RoHS.

  - Poles: 4

• - Coil voltage: 24 V DC
• - Current rating: up to 160 A under specified conditions
• - Auxiliary contacts: No
• - Reversing: Non-Reversing
• - Terminals: Screw
• - Frame/Series: Frame G
• XT series
• - Ingress protection: IP20
• no enclosure required
• - Voltage rating: rated for operation within the specified voltage range of up to 690V AC
• - Mounting: DIN Rail, Panel
• - Mechanical durability: approximately 10 million cycles under normal use conditions
• - Operating temperature: -13°F to 122°F
• - Certifications: UL Listed
• CE Marked
• CSA Certified
• EN 60947
• IEC 60947
• RoHS
