IEC Magnetic Contactor, 1NO, 24V AC, 4 P, Non-Reversing, Screw MPN:XTCF045C10T
Free Shipping
In Stock
The Eaton XT IEC magnetic contactor is a reliable and efficient switching device designed for non-reversing applications. Suitable for use in indoor environments, it operates on 24V AC and features four poles, including one normally open auxiliary contact. With a continuous ampere rating of up to 1000A and a maximum voltage rating of 690V AC, this contactor is ideal for resistive and inductive loads. Its compact design and durable construction make it perfect for use in industrial control panels, motor control centers, and other applications requiring a reliable and efficient switching solution.
Top product features:
- The Eaton XT IEC contactor has a 24V AC coil that uses electrical energy to open or close contacts.
- It is designed for non-reversing applications with four poles, including one normally open auxiliary contact.
- The contactor features screw terminals for wiring termination.
Top product applications:
- Industrial Automation
- HVAC Systems
- Power Distribution
The Eaton XT IEC contactor is an IEC Magnetic Contactor—an electrically operated switching device rated for operation within specified electrical parameters. It uses a 24V AC coil to open or close contacts and is designed for non-reversing applications with four poles, including one normally open auxiliary contact.
- Coil Voltage: 24 V AC
- - Action: designed for non-reversing applications
- - Poles: 4
- - Auxiliary Contacts: 1 NO
- - Contact Configuration: includes one normally open auxiliary contact as specified
- - Frame/Series: Frame C / XT
- - Contactor Style: IEC
- - Enclosure: does not include an enclosure
- suitable for use in appropriate environments
- - IP Rating: rated at IP20, suitable for indoor use in protected environments
- - Wiring Termination: Screw Terminals
- - Mounting Style: DIN Rail, Panel
- - Maximum Voltage Rating: rated for operation up to 690V AC within the specified electrical ratings
- - Continuous Ampere Rating: rated for continuous current up to 1000 A under specified conditions
- - Full Load Amperes: rated for resistive loads up to 45 A and inductive loads up to 25 A within the specified parameters
- - Frequency: 50/60 Hz
- - Certifications/Standards: CSA Certified
- UL Listed
- IEC 60947
- EN 60947
- CE Marked
- RoHS
- - Mechanical Durability: 10000000 cycles
- - Operating Temperature Range: designed to operate within temperatures from -13°F to 122°F (specified temperature range)
- - Dimensions: Width 4 in
- Depth 4.5 in
- Height 2.75 in
- - Mounting Hole Diameter: 0.16 in
- - Mounting Hole Distance (Height/Width): 2.95 in / 1.38 in
- - Embedded Surge Suppressor: Yes
- - Includes Auxiliary Contacts: Yes
