Circuit Breaker, PDG Series, 80A, 2 Pole, 600V AC, 25kA at 480V AC, A Curve MPN:PDG22F0080TFFL
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G300901950
Circuit Breaker, PDG Series, 80A, 2 Pole, 600V AC, 25kA at 480V AC, A Curve
Protect your electrical systems with the reliable PDG Series 80A, 2 Pole Circuit Breaker from Eaton. Suitable for use in a variety of applications, including commercial and industrial settings, this circuit breaker features a high interrupting capacity of 25kA at 480V AC and a thermal magnetic trip type for reliable overcurrent protection. Its compact design and standard terminals make it easy to install and integrate into existing systems, while its wide operating temperature range ensures reliable performance in a variety of environments. Ideal for use in panelboards and switchboards, this circuit breaker is a must-have for any electrical system.
Top product features:
- It has a thermal magnetic trip type for overcurrent protection.
- It can interrupt a maximum of 25kA at 480V AC.
- It is a 2-pole circuit breaker designed to handle three-phase applications.
Top product applications:
- Main Electrical Panel
- Commercial Lighting Systems
- Industrial Power Distribution Systems
Circuit Breaker, 80 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 25 kA at 480V AC, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Terminal Connection Standard Terminals Load Only, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection AB, Frame Size 225A/Frame 2, Height 6 in, Width 4.11 in, Depth 3.5 in, Min. Wire Size 14 AWG, Max. Wire Size 1/0 AWG, Max. Operating Temp. 158 Degrees F, Min. Operating Temp. -4 Degrees F
Additional Information
- Country of Origin: DO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.00
- Package Width: 6.00
- Package Height: 4.00
- Package Weight: 5.00
Product info last updated on January 13, 2026 1:00pm UTC
Category: Circuit Protection
