Cylindrical, Inductive Proximity Sensor, 18 mm Dia., Stainless Steel, 2 m, Bare Wire, 3 Wires, Semi-Shielded MPN:E57-18LE12-C1
Cylindrical, Inductive Proximity Sensor, 18 mm Dia., Stainless Steel, 2 m, Bare Wire, 3 Wires, Semi-Shielded
This cylindrical inductive proximity sensor is designed for use in a variety of applications, including industrial automation, material handling, and food processing. Its semi-shielded design and stainless steel construction make it ideal for use in harsh environments. With a maximum detecting distance of 12 mm and an operating frequency of 500 Hz, this sensor is highly sensitive and reliable. Its 3-wire NPN output and 6-48V DC power requirement make it easy to integrate into existing systems. The sensor is also resistant to extreme temperatures and can withstand exposure to water and dust.
Top product features:
- Cylindrical shape allows for easy installation in tight spaces
- Inductive technology detects metal objects without physical contact
- Semi-shielded design provides protection from electrical noise and interference
Top product applications:
- Automotive Parts Manufacturing
- Industrial Automation Systems
- Medical Device Assembly
Inductive Cylindrical Proximity Sensor, Inductive, 18 mm, Proximity Sensor Power Requirement 6 to 48V DC, Semi-Shielded, Proximity Sensor Operating Frequency 500 Hz, Proximity Sensor Output Circuit Type 3 Wire NPN, Max. Detecting Distance 12 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NC, NEMA Rating 12, 13, 4, 4X, 6, 6P, IP Rating IP67, IP69K, Case Material 303 Stainless Steel, Length 66 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 500mA
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 19 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.10
- Package Width: 1.90
- Package Height: 6.20
- Package Weight: 0.39
Product info last updated on January 13, 2026 1:36pm UTC
Category: Industrial Electrical Controls and Automation
