IEC Magnetic Contactor, No Auxiliary Contacts, 480V AC, 4 P, Non-Reversing, Screw MPN:XTCF080D00C

• The Eaton XT IEC contactor is an IEC magnetic contactor (4-pole, non-reversing) rated for operation within specified electrical parameters. It has a coil rated for use at 480 V AC within specified limits and is rated for loads up to 80 A under specified conditions, with screw terminals and no auxiliary contacts. This XT-series device features frame size D and is provided without an enclosure (IP20), compatible with DIN rail and panel mounting as per installation guidelines.

  - Amperage rating: rated for loads up to 80 A under specified conditions

• - Coil voltage: rated for use at 480 V AC within specified limits
• - Poles/configuration: 4P, Non-Reversing, No Auxiliary Contacts
• - Electrical connection: Screw terminals
• - Embedded surge suppressor: Yes
• - IP rating: IP20
• - Enclosure: No Enclosure
• - Mounting: compatible with DIN rail and panel mounting as per installation guidelines
• - Frame/Series/Code: XT frame D
• - Product name: Eaton XT IEC contactor
• - Dimensions: Width 5.75 in
• Height 3.54 in
• Depth 4.76 in
• - Certifications/standards: UL Listed
• EN 60947
• IEC 60947
• CE Marked
• RoHS
• CSA Certified
• - Maximum voltage rating: 690V AC
• - Operating temperature: -13°F to 122°F
• - Reversing: No
• - Contact configuration: 0 NO, 0 NC
• - Mechanical durability: 10000000 cycles
