IEC Magnetic Contactor, No Auxiliary Contacts, 24V DC, 3 P, Non-Reversing, Screw MPN:XTCE170G00TD
Free Shipping
In Stock
The Eaton IEC Magnetic Contactor is a versatile and reliable device suitable for a variety of industrial and commercial applications. Its non-reversing design and full voltage operation make it an ideal choice for controlling inductive and resistive loads. With a high amperage rating and robust mechanical operation, it can handle demanding power requirements. The contactor's compact design and flexible mounting options make it easy to integrate into existing systems. Suitable for use with single-phase and three-phase power supplies, this device is a reliable solution for applications such as motor control, lighting, and HVAC systems in industrial and commercial settings.
Top product features:
- Compliance with multiple standards including UL Listed, CSA Certified, IEC 60947, EN 60947, CE Marked.
- Operating temperatures should fall between -13 degrees F and 122 degrees F.
- Mechanical operation has been tested up to ten million cycles.
Top product applications:
- Industrial control systems
- Commercial settings
- Residential HVAC systems
The EATON - IEC Magnetic Contactor is a non-reversing, full voltage contactor suitable for use in a variety of industrial and commercial settings. Rated to function within the specified range of 24V DC coil voltage, it has an amperage rating of 170A for inductive loads and 275A for resistive loads. This device does not include auxiliary contacts, utilizing screw terminals instead for its electrical connection. The contactor is enclosed in a Frame G size housing, which does not have an additional NEMA rating. It has been given an IP20 rating, suggesting it can withstand exposure to solid objects up to 12mm. The product does not claim any level of water resistance.
Key features of this product include:
- - Compliance with multiple standards including UL Listed, CSA Certified, IEC 60947, EN 60947, CE Marked.
- - Operating temperatures should fall between -13 degrees F and 122 degrees F.
- - Mechanical operation has been tested up to ten million cycles.
- - Can be used with different horsepower ratings across single-phase (10hp at 120v AC
- 30hp at240v AC)and three-phase power supplies(40hp at208vAC
- 60hp at240vAC
- and125hpat480&600 VAC).
- - Compatible with both DIN Rail and Panel mounting styles for flexible installation options.
- - Response times ranging from less than30 msec (DC Operated Opening Delay) to less than41 msec (AC Operated Opening Delay). Please note that the overall dimensions are approximately: height –6.69 inches
- width –4.37 inches
- depth –6.3 inches.
Additional Information
- Country of Origin: RO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 7.40
- Package Height: 4.00
- Package Weight: 5.15
