IEC Magnetic Contactor, 1NC/1NO, 480V AC, 3 P, Reversing, Screw MPN:XTCR170G11C
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient solution for controlling power circuits in a variety of applications, including industrial automation, HVAC systems, and more. With its reversing action and three-pole design, it can handle complex control sequences and provide smooth operation. The contactor's 480V AC coil voltage and 170A/275A amperage ratings make it suitable for high-power applications. Its compact design and screw terminals ensure easy installation and connection. Ideal for use in commercial and industrial settings, the Eaton XT IEC contactor offers increased productivity, improved safety, and reduced downtime.
Top product features:
- Reversing action
- Three poles
- Embedded surge suppressor
Top product applications:
- Three-pole, IEC magnetic contactor with reversing action for use in power circuits
- Full voltage reversing contactor for applications requiring bidirectional control
- Inductive load control in applications such as motor control and power distribution
The Eaton XT IEC contactor is a three-pole, IEC magnetic contactor with reversing action. It is rated for controlling power circuits within specified parameters and is rated for operation with a coil voltage of 480 V AC. The unit includes 1 normally open and 1 normally closed auxiliary contact (2 total), screw terminals, and an embedded surge suppressor. The contactor is part of the XT series, frame size G
- it is provided without an enclosure.
Key features
- - Reversing action
- three poles
- intended for use as a full voltage reversing contactor
- - Coil voltage: 480 V AC
- - Rated for applications up to these amperage levels under specified conditions (Inductive 170 A
- Resistive 275 A)
- - Auxiliary contacts: 2 (1NO/1NC)
- Contact configuration: 1 NO, 1 NC
- Includes an embedded surge suppression component (note that performance may vary)
- - Electrical connection: Screw terminals
- Mounting style: DIN Rail, Panel within specified installation guidelines
- - Frame size: G
- Series: XT
- Product name: Eaton XT IEC contactor
- - Enclosure: No Enclosure
- IP rating: IP20 -> Does not include an enclosure
- rated IP20 per standard specifications
- - Certifications and standards: Complies with applicable standards and certifications (see specific product documentation)
- - Dimensions: Height 8.25 in
- Width 18.5 in
- Depth 10.5 in
- - Operating range: Frequency 50/60 Hz
- Maximum operating temperature 122°F
- Minimum operating temperature -13°F
- - Mounting hole diameter: 0.27 in
- Mounting hole distances (Height 11.77 in, Width 6.97 in)
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.40
- Package Width: 10.80
- Package Height: 7.60
- Package Weight: 16.17
