IEC Magnetic Contactor, 1NC, 240V AC, 3 P, Non-Reversing, Screw MPN:XTCE018C01B

• Eaton XT IEC contactor. This IEC magnetic contactor is a 3-pole, non-reversing device with a 240 V AC coil. It uses screw terminals, has no enclosure, and is sized Frame C for DIN Rail or Panel mounting. It is rated for operation within the specified voltage and frequency ranges.

  - Action: Non-Reversing

• - Poles: 3
• - Coil Voltage: 240 V AC
• - Amperage Rating: 18 A
• - Full Load Amps (Inductive): 18 A
• - Full Load Amps (Resistive): 40 A
• - Auxiliary Contacts: Yes (1NC)
• - Auxiliary Contact Configuration: 1NC
• - Contact Configuration: 1 NC
• - Electrical Connection: Screw Terminals
• - Frame Size / Series: Frame C / XT
• - Mounting Style: DIN Rail, Panel
• - Enclosure: No Enclosure
• - IP Rating: IP20
• - Rated for operation up to 690 V AC
• - Frequency Rating: 50-60 Hz
• - Includes a surge suppression component
• - Mechanical Operating Durability: 10,000,000 cycles
• - Certifications: UL Listed
• CSA Certified
• IEC 60947
• EN 60947
• - CE Marked: Yes
• - Includes Auxiliary Contacts: Yes
• - Number of Aux Contacts: 1
• - Reversing: No
