IEC Magnetic Contactor, 1NO, 120V AC, 4 P, Non-Reversing, Screw MPN:XTCF045C10A
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient solution for switching applications in various industries. Its non-reversing, four-pole design and 120V AC coil make it suitable for use in control panels and electrical systems. With a rating of up to 45A, it can handle high current loads, and the embedded surge suppressor protects against voltage spikes. This contactor is ideal for applications such as motor control, lighting, and HVAC systems, and its compact design makes it suitable for DIN rail or panel mounting. Its IP20 rating ensures safe operation in harsh environments.
Top product features:
- The Eaton XT IEC contactor has a non-reversing action.
- It features a four-pole configuration.
- It includes an embedded surge suppressor.
Top product applications:
- Industrial control systems
- Motor control circuits
- Automated manufacturing equipment
The Eaton XT IEC contactor is rated for switching applications within specified parameters. Configured as a non-reversing, four-pole contactor with a 120V AC coil and rated for up to 45A in accordance with applicable standards, containing one normally open auxiliary contact according to product specifications. Compatible with DIN rail or panel mounting methods as specified by the manufacturer, featuring an integrated surge suppression component in accordance with design specifications. IP20 rating
- no enclosure
- XT series (frame size C)
- rated for up to 690V AC at 50/60 Hz.
- Action: Non-Reversing
- - Reversing: No
- - Number of Poles: 4
- - Coil Voltage: 120V AC
- - Amperage Rating: 45A
- - Auxiliary Contacts: 1NO
- - Contact Configuration: 1 NO
- - Frame Size: C
- - Frame/Series: XT
- - Contactor Style: IEC
- - Type: Full voltage non-reversing contactor
- - Maximum Voltage Rating: 690V AC
- - Frequency: 50/60 Hz
- - Embedded Surge Suppressor: Yes
- - Electrical Connection: Screw Terminals
- - Mounting Style: DIN Rail, Panel
- - IP Rating: IP20
- - Enclosure: No Enclosure
- - Certifications: UL Listed
- CSA Certified
- IEC 60947
- EN 60947
- - Standards: CE
- CSA
- EN 60947
- IEC 60947
- RoHS
- UL Listed
- - Operating Temperature: -13°F to 122°F
- - Dimensions: Width 2.28 in
- Height 3.35 in
- Depth 3.83 in
- - Product Name: Eaton XT IEC contactor
- - Series: XT
The detailed specifications are provided for informational purposes only and do not constitute guarantees of performance or safety.
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 4.00
- Package Height: 3.00
- Package Weight: 1.19
