IEC Magnetic Contactor, 1NC, 24V DC, 3 P, Non-Reversing, Screw MPN:XTCE009B01TD
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient solution for controlling power circuits in a variety of applications. Suitable for use in industrial and commercial settings, this 3-pole contactor features a 24V DC coil and a 1NC auxiliary contact, providing a non-reversing action. Its compact design and screw terminals make it easy to install and mount on DIN rail or in a panel. With a maximum voltage rating of 690V AC and an IP20 enclosure rating, this contactor is ideal for use in a range of industries, including manufacturing, oil and gas, and food processing.
Top product features:
- The Eaton XT IEC contactor is a 3-pole device with a non-reversing action.
- It includes a 1NC auxiliary contact for additional functionality.
- It is designed to operate at a maximum voltage of 690 V AC.
Top product applications:
- Control of Power Circuits
- Industrial Automation Systems
- Machine Control Systems
The Eaton XT IEC contactor is an IEC magnetic contactor designed to control power circuits. It is a 3-pole, non-reversing device with a 24 V DC coil, and it includes a 1NC auxiliary contact. The unit uses screw terminals, sits in Frame B of the XT series, and is rated for up to 690 V AC with an IP20 enclosure rating. It is intended for panel or DIN rail mounting and does not include an enclosure. Dimensions are 3 in wide, 2 in high, and 3 in deep.
Key features
- - Poles: 3
- - Coil voltage: 24 V DC
- - Action: Non-Reversing
- - Auxiliary contacts: 1 NC
- - Contact configuration: 1 NC
- - Terminals: Screw
- - Frame/Series: Frame B, XT
- - Maximum voltage: 690 V AC
- - IP rating: IP20
- - Enclosure: No Enclosure
- - Mounting: DIN Rail, Panel
- - Mechanical durability: The mechanical durability indicates the number of operational cycles but does not guarantee performance over this lifespan.
- - Electrical operating durability: These figures specify typical electrical endurance ratings under test conditions
- actual performance may vary based on application and usage conditions.
- - Full load current: Inductive 9 A
- Resistive 22 A
- - Frequency: 50/60 Hz
- - Certifications/standards: UL Listed
- CSA Certified
- EN 60947
- IEC 60947
- RoHS
- CE Marked
- - Temperature range: -13°F to 122°F
- - Dimensions: 3 in W x 2 in H x 3 in D
- - Reversing: No
- - Product name: Eaton XT IEC contactor
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.80
- Package Width: 1.90
- Package Height: 3.20
- Package Weight: 0.67
