IEC Magnetic Contactor, 1NO, 240V AC, 4 P, Non-Reversing, Screw MPN:XTCF045C10B
Free Shipping
In Stock
The Eaton IEC Magnetic Contactor is a reliable and efficient solution for controlling industrial electrical systems. Suitable for use in a variety of applications, including motor control, lighting, and HVAC, this 4-pole, non-reversing contactor features a 240V AC coil and screw terminals. Its embedded surge suppressor and IP20 rating provide added protection and durability. With a mechanical durability of 10,000,000 cycles and operating temperature range of -13°F to 122°F, this contactor is designed to withstand harsh environments and heavy use. Ideal for use in a range of industries, including manufacturing, oil and gas, and food processing.
Top product features:
- Embedded surge suppressor
- Non-reversing action
- One normally open auxiliary contact
Top product applications:
- Industrial control systems for manufacturing and production environments
- Motor control circuits for HVAC systems
- Automated conveyor systems in packaging and material handling applications
The IEC Magnetic Contactor is a 4-pole, non-reversing, electrically operated switch rated for operation within the specified voltage and current ranges as per IEC standards. It uses a 240 V AC coil and screw terminals, and is part of the XT series (Frame C, Size C). It contains one normally open auxiliary contact
- features include an embedded surge suppressor
- rated IP20 without enclosure. Suitable for mounting on DIN rail or panel according to installation guidelines.
- Action: Non-Reversing
- Reversing: No
- - Aux Contacts: 1 NO (Configuration: 1NO
- Form: 1NO)
- - Coil Voltage: 240 V AC
- - Embedded Surge Suppressor: Yes
- - Enclosure: No Enclosure
- IP20
- - Mounting Style: DIN Rail, Panel
- - Frame/Series: Frame C
- XT
- - Frequency: 50/60 Hz
- - Phase: Three
- - Maximum Voltage Rating: 690 V AC
- - Full Load Currents: Inductive 25 A
- Resistive 45 A
- - HP Ratings: 7-1/2 hp (1 Ph 240V)
- 10 hp (3 Ph 240V)
- 15 hp (3 Ph 480V)
- 20 hp (3 Ph 600V)
- - Mechanical Durability: 10,000,000 cycles
- - Operating Temperature: -13°F to 122°F
- - Terminal Connection: Screw
- - Dimensions: Width 2.28 in
- Height 3.35 in
- Overall Depth 5.43 in
- - Standards: CE, CSA, EN/IEC 60947, RoHS, UL Listed
Additional Information
- Country of Origin: RO
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 4.00
- Package Height: 2.80
- Package Weight: 1.20
