IEC Magnetic Contactor, 1NC, 24V AC, 3 P, Non-Reversing, Screw MPN:XTCE018C01T
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient solution for a wide range of applications, including industrial control systems, motor control, and power distribution. Its 24V AC coil and three poles make it suitable for use in various industries, such as manufacturing, oil and gas, and food processing. The non-reversing action and screw terminals provide a secure and easy-to-use connection. With a lifespan of 2 million switching cycles and 10 million operating cycles, this contactor ensures high durability and reliability. It is certified to meet international standards and is CE marked, making it a great choice for global projects.
Top product features:
- Non-Reversing action
- 1NC auxiliary contact
- Screw terminals
Top product applications:
- Motor Control Circuits
- Automotive Applications
- Industrial Control Systems
The Eaton XT IEC contactor is an IEC magnetic contactor with a 24V AC coil and three poles. It is configured as non-reversing and uses screw terminals, and includes one 1NC auxiliary contact. It is part of the XT series and uses Frame size C.
Key features
- - Coil voltage: 24V AC
- - Action: Non-Reversing
- - Poles: 3
- - Auxiliary contacts: 1NC (Includes 1 auxiliary contact)
- - Terminals: Screw terminals
- - Frame/Series: Frame C, XT
- - Rated voltage: up to 690V AC in accordance with specifications
- - IP rating: IP20
- - Mounting: DIN Rail, Panel
- - Enclosure: No Enclosure
- - Frequency: 50/60 Hz
- - Electrical durability: rated for an electrical lifespan of approximately 2,000,000 switching cycles under normal conditions
- - Mechanical durability: rated for a mechanical lifespan of approximately 10,000,000 operating cycles under normal conditions
- - Certifications: CE Marked
- CSA Certified
- UL Listed
- EN 60947
- IEC 60947
- RoHS
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.50
- Package Width: 1.90
- Package Height: 4.00
- Package Weight: 1.00
