Cylindrical, Inductive Proximity Sensor, 12 mm Dia., Stainless Steel, Micro, 2 Wires, Shielded MPN:E59-M12A105A01-A1
Cylindrical, Inductive Proximity Sensor, 12 mm Dia., Stainless Steel, Micro, 2 Wires, Shielded
This inductive proximity sensor is a reliable and versatile solution for detecting objects in a variety of applications. With its cylindrical design and stainless steel construction, it can withstand harsh environments and extreme temperatures. The sensor is easy to integrate, requiring only 2 wires and a simple connection to a 20-132V AC power source. It can detect objects up to 4mm away and operates at a frequency of 30Hz. Suitable for use in industrial settings, food processing, and pharmaceutical applications, this sensor provides a high level of accuracy and durability, making it an excellent choice for demanding environments.
Top product features:
- Cylindrical design allows for easy installation in tight spaces
- Detects objects up to 4 mm away
- Operates at a wide temperature range of -40 to 158 Degrees F
Top product applications:
- Automotive applications due to its IP67 and IP69K ratings for use in harsh environments.
- Medical equipment and devices where a high level of cleanliness and resistance to corrosion is required.
- Food processing and packaging machinery where the sensor's stainless steel construction and high IP rating make it suitable for use in wet and corrosive environments.
Inductive Cylindrical Proximity Sensor, Inductive, 12 mm, Proximity Sensor Power Requirement 20 to 132V AC, Shielded, Proximity Sensor Operating Frequency 30 Hz, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 4 mm, Proximity Sensor Electrical Connection 3 Pin Micro AC Connector, Output Mode NO, NEMA Rating 12, 13, 4, 4X, 6, 6P, IP Rating IP67, IP69K, Case Material 303 Stainless Steel, Length 69 mm, Operating Temp. Range -40 Degrees to 158 Degrees F, Max. Current Load 250mA
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.40
- Package Width: 2.10
- Package Height: 2.10
- Package Weight: 0.15
Product info last updated on March 2, 2026 11:22am UTC
Category: Industrial Electrical Controls and Automation
