IEC Magnetic Contactor, 1NC/1NO, 240V AC, 3 P, Reversing, Screw MPN:XTCR080F11B

• The Eaton XT IEC contactor is a three-pole, reversing, electrically operated switching device rated for operation within the specified IEC standards. It features a 240 V AC coil and is capable of reversing motor direction. The unit includes 2 auxiliary contacts (1 normally open / 1 normally closed) and uses screw terminals for wiring. Its mounting options are DIN Rail or Panel, with no enclosure (IP20). Frame Size F and Series XT identify the standard form and family. It carries multiple certifications (IEC 60947

• EN 60947
• UL Listed
• CSA Certified
• CE Marked
• RoHS) and includes an embedded surge suppressor. Operational frequency is 50/60 Hz, with a maximum ambient rating of 122°F and minimum of -13°F.

  - Coil Voltage: 240 V AC – energizes the contactor to operate

• - Action: Reversing – allows current direction to be reversed
• - Poles: 3 – three-pole configuration
• - Auxiliary Contacts: 2 total (1 NO / 1 NC) – signaling/control contacts
• - Electrical Connection: Screw terminals
• - Mounting: DIN Rail, Panel
• - Enclosure/IP: No Enclosure
• IP20
• - Frame/Series: Frame F
• XT
• - Certifications/Compliances: IEC 60947
• EN 60947
• UL Listed
• CSA Certified
• CE Marked
• RoHS
• - Embedded Surge Suppressor: Yes
• - Frequency: 50/60 Hz
• - Rated for use at currents up to: Inductive 80 A
• Resistive 110 A
• - Product Name: Eaton XT IEC contactor
• - Type: Full voltage reversing contactor
• - Dimensions: Width 6.54 in
• Height 6.14 in
• Depth 5.08 in
