IEC Magnetic Contactor, 1NC, 208V AC, 3 P, Non-Reversing, Screw MPN:XTCE018C01E
Free Shipping
In Stock
The Eaton XT IEC contactor is a reliable and efficient solution for a wide range of applications, including industrial control systems, HVAC, and power distribution. Its three-pole, non-reversing design ensures safe and precise control of heavy loads, while the 1 NC auxiliary contact provides additional functionality. With a current rating of 18 A for inductive loads and 40 A for resistive loads, this contactor is suitable for various industrial environments. Its compact design and screw terminal connections make it easy to install and integrate into existing systems, providing a reliable and cost-effective solution for industrial control needs.
Top product features:
- Three-pole, non-reversing IEC contactor configuration
- Operated by a 208 V AC, 60 Hz coil
- Rated for operation within the specified voltage range
Top product applications:
- Industrial control systems
- Motor control applications
- Power distribution systems
The Eaton XT IEC contactor is a three-pole, non-reversing IEC magnetic contactor with a 1 NC auxiliary contact. It is operated by a 208 V AC, 60 Hz coil and uses screw terminals with DIN Rail or panel mounting. Voltage rating: rated for operation within the specified voltage range. Current rating: is rated for the specified current and load conditions (Inductive: 18 A
- Resistive: 40 A). It is part of the XT series, frame size C.
Key features
- - Configuration: Three-pole, non-reversing IEC contactor
- - Coil: 208 V AC, 60 Hz
- - Current rating: rated for the specified current and load conditions (Inductive: 18 A
- Resistive: 40 A)
- - Auxiliary contact: 1 NC (Form 1NC)
- - Terminals: Screw terminals
- Mounting style: DIN Rail or panel
- - Frame/Series: XT
- Frame C
- - Enclosure: No enclosure
- IP20
- - Voltage rating: rated for operation within the specified voltage range
- - Certifications/Standards: CSA Certified
- UL Listed
- EN 60947
- IEC 60947
- CE Marked
- RoHS
- - Dimensions (approx.): Width 1.85 in
- Depth 3.82 in
- Height 3.90 in
- - Product Name: Eaton XT IEC contactor
Additional Information
- Country of Origin: RO
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.50
- Package Width: 2.00
- Package Height: 4.00
- Package Weight: 1.00
